SPECIFICATIONS
FRAMESET
FRAME X6 series 29″ alloy dual suspended Single Pivot frame, 120mm rear travel, tapered 1.5″ head tube, 73mm BB shell, Enduro bearings, 9mm Q/R rear dropouts
FORK SR Suntour Raidon-XC-LO-R-29.0; 1.5″ tapered alloy steerer, 120mm travel, air spring w/ hydraulic lockout
FRAME SHOCK Suntour Raidon R, 190X51
COLORS Black/Neon
WEIGHT 32lbs
DRIVETRAIN
CRANKS Suntour Zeron 1X AX-S-30, 30T Steel Zig-Zag Chainring
PEDALS N/A
CHAIN KMC X10 NP/GY, w/ Missing Link
BOTTOM BRACKET Suntour BB-BKA008-C, 73mm, sealed cartridge
FRONT DERAILLEUR
REAR DERAILLEUR Shimano Deore RD-M6000, 10-spd, Top Normal, Shadow Plus design
DERAILLEUR SHIFTER Shimano Deore M6000, right only, 1×10-spd, w/ optical gear display
FREEWHEEL/CASSETTE SunRace CSMS3 10-spd 11-46T Metallic Silver
WHEELS
TIRES Kenda Honey Badger 29*2.20, 30tpi
WHEELS/RIMS Pivit XD-260 Disc, 29″ x 32h alloy double wall
HUBS Shimano TX-505 alloy, Center Lock Disc, cassette 32h
BRAKING SYSTEM
BRAKES Shimano hydraulic BR-MT200 180/160mm Center Lock rotors
BRAKE LEVERS Shimano BL-MT200 hydraulic
OTHER COMPONENTS
GRIPS/TAPE WTB Weirwolf
HANDLE BAR Pivit alloy 20mm riser bar 31.8mm, 700 / 720mm, 9 Deg. sweep
STEM Pivit alloy Trail 0 Deg., 4 bolts, ext.: 60mm
HEADSET FPD DOZER-1160A-2 w/ 1.5″ ACB bottom for 44/56mm head tube, w/ 8mm Top Cone
SADDLE WTB Volt Sport w/ color accents
SEAT POST Pivit alloy micro adjust 31.6mm, 350mm
SEAT CLAMP Pivit alloy 35mm quick release
EXTRAS Frame bearings by Enduro USA
