SPECIFICATIONS

Model RA RL TNL MLC T
STEERER 28.6mm Steel
CROWN 130mm Aluminum ED Black
STANCHION 30mm Steel, CP color
LOWER Aluminum 9mm Open Dropout
FEATURES Hydraulic
Remote lock-out		 Hydraulic
Remote Lock-out		 Hydraulic
Lock-out		 Mechanical
Lock-out		 –
DAMPER TNL TNL TNL ML –
SPRING Coil
ADJUSTMENT R, P RL, P L, P L, P P
TRAVEL(MM) 80, 100, 120mm
FORK OFFSET 51mm
FORK HEIGHT 500 / 520 / 540
BRAKE TYPE Disc only
DISK BRAKE MOUNT Post
MAX ROTOR SIZE 180mm
WHEEL SIZE 29″
WEIGHT
(W/200MM STEERER)		 2.81 kg 2.90 kg 2.84 kg 2.61 kg 2.61 kg
